LumiCore

SKU: 074 Category:

Description

The LumiCore is a network node from the LumiNode range.

With 64 built-in engines, LumiCore allows you to merge and route up to 64 x 4 input sources toward 64 newly defined universes. This way, LumiCore becomes the ideal solution to isolate your control setup on a festival, a theater or in a TV studio.
As technology is evolving towards full networked solutions (ArtNet or sACN directly to the fixtures), LumiCore provides all the flexibility of the LumiNode but then directly on the network, with up to 256 input universes merged and routed towards max 128 output universes. All of this with extreme low latency.
The engine technology allows you to merge in HTP, LTP, Backup, Switch, Crossfade or custom mode, with different triggers that can be assigned even on a per channel basis.

In large pixel mapping applications LumiCore is the ideal bridge to merge different control sources into new network streams.
You can also use LumiCore as plugin device for a touring BlackTrax or automated follow spot system by inserting merged results as a higher priority on the network with same sACN universe numbers.
In TV studio’s LumiCore will allow you to have control desks in the IT environment by bridging the local lighting rig and isolating it from their show critical control part.
For festivals, Lumicore will be your ideal companion to facilitate all of your lighting setups and host the most advanced and flexible data system to your guest acts and upcoming headliners.

All this comes in a half 19″ rugged enclosure. Ideal to scale in the network or to double for full redundancy in 1U.

Additional information

Process engines

64

Merging engine

HTP, LTP, Backup, Switch, X-Fade, Custom

Softpatch

Yes

Trigger system

Yes

ReRoute

Yes

Profile Manager

Yes

Snapshot

Yes

Monitoring software

LumiNet Monitor V2 (free)

DMX Port Direction

NA

DMX port isolation

NA

DMX Port termination/biasing

NA

DMX timing

NA

Ethernet port speed

1Gbps

Port sensing

Auto-negociation, MDI / MDIX

DMX connectivity

None

Ethernet connectivity

2x shielded Neutrik Ethercon connector

Power connectivity

1x Neutrik powerCON TRUE1, Ethernet (PoE)

Power input

100-240VAC 50-60Hz, PoE (802.3af)

Power consumption

Maximum 13W

PoE powered

Yes IEEE 802.3af (class 0 rated)

DMX protocols

NA

Ethernet protocols

Art-Net™ (1-4), sACN ANSI E1.31, RTTrPL (BlackTraX)

Certificates/Approvals

cSGSus Mark, CE, CB certificate

Display and jog

Yes

Status LEDs

Ethernet Port link/activity LED and mode LED

Mounting

Rack, Truss

Enclosure

Robust metal housing

Dimensions (W x D x H)

220 x 175 x 44 mm (1/2 19" x 8,7" x 1,7")

Weight

2,4 kg

Packaging

530 x 330 x 80 mm (21" x 13" x 3,15")

Environment

Operating temperature: 0 tot +60°C, Storage temperature: -10 tot +70°C, Humidity (non condensing): 5 to 95% RH

URL

https://www.luminex.be/products/luminode/lumicore/

Configuration

Through the built-in web server or with the front end display menu

Product codes

LU 01 00074 (LumiCore with PoE input)

Position

1

Standards

IEC 60950-1, UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, FCC Part 15 CFR 47, CAN/ICES-003, EN 55022, EN 55024
